Pioneer GM-DC971 Champion Series PRO Class-D Mono Amplifier
Champion Series PRO Class-D Mono Amplifier 2400W Max / 1200W RMS at 1 ohm Tuned to deliver deeper and louder bass Champion Series Design Variable LPF RCA Input Speaker Input Bass Boost Give more juice to your sound. Two-step Bass Boost allows precise control for optimal bass, giving you enhanced sound impact based on your music choice and style.
Overview
Product details
Champion Series PRO Class-D Mono Amplifier 2400W Max / 1200W RMS at 1 ohm Tuned to deliver deeper and louder bass Champion Series Design Variable LPF RCA Input Speaker Input Bass Boost Give more juice to your sound. Two-step Bass Boost allows precise control for optimal bass, giving you enhanced sound impact based on your music choice and style.
Read full product description
RCA Input Use your RCA interconnect cables for hassle-free linking of the amplifier to the source unit. Speaker Input Allows you to connect the amplifier to your source without RCA-type inputs and without the need for adapters. Variable LPF Allows adjustment of the Low-Pass Filter according to your listening preference.
Product context
Amplifiers products are easier to compare with the right specs.
Use the product name, SKU, category, brand, images, price and spec sections to compare this item against the rest of the catalogue. Product pages are designed to make online shopping easier before an order is placed.
Technical specs
Product spec sections
Old site attributes4 specs
- Amplifier channels
- 1
- Amplifier RMS power output
- 1200
- Amplifier impedance
- 1 Ohm
- Amplifier class
- Class D
Technical specs16 specs
- Amplifier Class
- Class D
- No. of Channels
- Mono
- Max. Power Output
- 1,000 W x 1 (4Ω) / 1,600 W x 1 (2Ω) / 2,400 W x 1 (1Ω)
- RMS Power Output
- 500 W x 1 (4Ω) / 800 W x 1 (2Ω) / 1,200 W x 1 (1Ω)
- Frequency Response
- 10 Hz to 240 Hz
- Impedance
- 1Ω to 8Ω
- Total Harmonic Distortion (THD)
- <0.5% (100 Hz)
- S/N Ratio
- 100 dB
- Speaker Level Input
- Yes
- Automatic Signal Sensing and Turn-On
- Yes
- Crossover Type
- Variable LPF
- Crossover Frequency
- 40 Hz to 240 Hz
- Bass Boost Frequency
- 56 Hz
- Bass Boost Level
- 0 dB to 18 dB
- Bass Boost Remote
- No
- Dimensions
- 302 mm x 60 mm x 215 mm
